Clymer - Harley Davidson 1959 - 1985 Sportster Service Manual

Clymer Sportster Service Manual 1959-1985

Included in this manual:

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING

CHAPTER THREE / PERIODIC LUBRICATION, MAINTENANCE AND TUNE-UP
Maintenance schedule intervals / Periodic lubrication / Engine oil and filter change / Periodic maintenance / Suspension adjustment / Breaker point ignition service / Magneto / Breakerless ignition system / Carburetor adjustments

CHAPTER FOUR / ENGINE
Removal installation / Pushrods / Valves and components / Cylinder / Oil pump / Gearcase / Tappets and guides / Crankcase / Drive sprocket and seal / Engine seals / Starter drive shaft and housing / Specifications

CHAPTER FIVE / CLUTCH, PRIMARY DRIVE, KICKSTARTER AND TRANSMISSION
Clutch / Primary chain / Kickstarter / Transmission / Shifter mechanism / Shifter linkage / Specifications

CHAPTER SIX / FUEL, EXHAUST AND EMISSION CONTROL SYSTEMS
Air cleaner / Carburetors / Throttle cable / Fuel shutoff valve / Fuel tank / Exhaust system / Emission control / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Charging system / Magneto ignition system / Battery ignition / Ignition system / Ignition coil / Starter / Starter solenoid / Lighting system / Switches / Horn / Fuses and circuit breakers / Specifications

CHAPTER EIGHT / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Wheel balance / Tire changing / Tire repairs / Handlebar and throttle control / Steering head / Front fork / Specifications

CHAPTER NINE / REAR SUSPENSION
Rear wheel / Rear hub / Driven sprocket assembly / Drive chain / Wheel balancing / Tire changing / Rear swing arm / Shock absorbers / Specifications

CHAPTER TEN / BRAKES
Drum brakes / Front and rear drum brakes / Disc brakes / Brake pads / Brake caliper / Front and rear master cylinder / Brake disc / Bleeding the system / Specifications

INDEX

WIRING DIAGRAMS
